產品特點
1.高放大倍率 2.可接三腳架，外接輔助光源燈，手柄
3.先進的光學系統 4.高分辨率
5.精致耐用的材質 6.內置紅外輔助照明器
7.可靠易操作性強 8.2年保修期，終生維護
產品參數
|
參數
|
指標
|
|
增強管
|
二代加
|
|
鏡頭
|
第三代光學鏡頭
|
|
分辨率
|
45-53lp/mm
|
|
物鏡倍率Lens magnification,x
|
5
|
|
物鏡系統Lens systems
|
80mmF/1.7
|
|
視場Field of view,deg
|
12.5
|
|
調焦范圍Focus range,m
|
1.5 to infinity
|
|
物鏡直徑Objective lens diameter,mm
|
50
|
|
重量Weight,g
|
680
|
|
尺寸Overall dimensions,mm
|
182X100x65
|
|
觀察距離Detecyion range,m
|
500
|
|
瞳孔直徑Exit pupil duaneter,mm
|
6
|
|
屈光度Eyepiece Duioer adjustment,dptr
|
+4/-4
|
|
瞳孔距離Eye relief,mm
|
15
|
|
電池壽命（開IR）Battery life IR on,hour
|
Up to 20小時
|
|
電池壽命（關IR）Battery life IR on,hour
|
Up to 60小時
|
|
IR功率IR Power,mw
|
25≤
|
|
IR波長IR wavelength,nm
|
850
|
|
防水標準IP standard of water-resistence
|
IPX4
|
|
濕度Humidity,%
|
93
|
|
操作溫度Operating temperature,℃
|
-40°to+50°
|
|
儲藏溫度Storage temperature,℃
|
0°to+50°
|
|
|
